LTE Router im Vergleich
Embedded 4G LTE / 3G | Cellular Modem | Redundant SIM slots | USB 4G LTE / 3G WAN | Ethernet WAN | Ethernet LAN | Router Throughput | Caching Capacity | Port-Based VLAN | |
BR1 Classic | 1 | LTE | 1 (FE) | 2 (FE) | 100 Mbps | ||||
BR1 MK2 | 1 | LTE / LTE-A | 1 (GE) | 1 (GE) | 100 Mbps | ||||
BR1 Mini | 1 | LTE / LTE-A | 0-1 (FE) * | 1-2 (FE) * | 100 Mbps | ||||
BR1 M2M | 1 | LTE | 1 (FE) | 1 (FE) | 100 Mbps | ||||
BR1-Slim | 1 | LTE | 1 (FE) * | 1 (FE) | 100 Mbps | ||||
BR1-ENT | 1 | LTE / LTE-A | 1 | 1 (GE) * | 2 (GE) | 300 Mbps | |||
BR1-Pro | 1 | LTE / LTE-A | 1 (FE) | 4 (GE) | 120 Mbps | ||||
Hotspot | 1 | LTE / LTE-A | 1 (GE) | 1 (GE) | 150 Mbps | ||||
Transit | 1 to 2 | LTE / LTE-A | 1 (GE) * | 1 (GE) | 400 Mbps | ||||
Embedded 4G LTE / 3G | Cellular Modem | Redundant SIM slots | USB 4G LTE / 3G WAN | Ethernet WAN | Ethernet LAN | Router Throughput | Caching Capacity | Port-Based VLAN | |
HD2 | 2 | LTE / LTE-A | 1 | 2 (GE) | 4 (GE) | 400 Mbps | |||
HD2 Mini | 2 | LTE / LTE-A | 1 | 1 (GE) | 2 (GE) | 300 Mbps | |||
HD4 | 4 | LTE / LTE-A | 1 | 2 (GE) | 8 (GE) | 400 Mbps | |||
HD2/4 with MFA | 2 or 4 | LTE / LTE-A | 1 | 2 (GE) | 8 (GE) | 400 Mbps | 150Mbps 120GB SSD | ||
On-The-Go | n/a | 4 | 1 (FE) * | 1 (GE) | 100 Mbps | ||||
700 | n/a | 4 | 2 (GE) | 4 (GE) | 400 Mbps | ||||
BR1 IP55 | 1 | LTE / LTE-A | 1 (GE) * | 2 (GE) | 100 Mbps | ||||
BR2 IP55 | 2 | 3G | 1 (GE) * | 2 (GE) | 100 Mbps | ||||
BR1 IP67 | 1 | LTE / LTE-A | 1 (FE) | 100 Mbps | |||||
HD2 IP67 | 2 | LTE / LTE-A | 1 (GE) * | 1 (GE) | 200 Mbps |
Wi-Fi Radio 1 | Wi-Fi Radio 2 | Wi-Fi Data Rates | 5GHz Radio Supports Wi-Fi WAN | Simulataneous Dual-Band AP | SSID Supported | Wi-Fi as WAN and AP | Max. AP Supported By AP Controller | |
BR1 Classic | 802.11b/g/n | 2.4GHz: 150Mbps | 16 | |||||
BR1 MK2 | 802.11ac/a/n | 802.11b/g/n | 2x2 MIMO, 2.4GHz:300Mbps/ 5GHz:866Mps | 16 | ||||
BR1 Mini | 802.11b/g/n | 2.4GHz: 150Mbps | 16 | * | ||||
BR1 M2M | n/a | |||||||
BR1-Slim | 802.11b/g/n | 2.4GHz: 150Mbps | 16 | |||||
BR1-ENT | n/a | |||||||
BR1-Pro | 802.11a/g/n | 802.11a/g/n | 2x2 MIMO, 2.4GHz:300Mbps | 16 | ||||
Hotspot | 802.11ac/a/n | 802.11b/g/n | 3x3 MIMO, 2.4GHz:450Mbps 5GHz:1300Mbps | 16 | ||||
Transit | 802.11ac/a/b/g/n | 802.11ac/a/b/g/n | 2x2 MIMO, 2.4GHz:300Mbps | * | 16 | 30 | ||
Wi-Fi Radio 1 | Wi-Fi Radio 2 | Wi-Fi Data Rates | 5GHz Radio Supports Wi-Fi WAN | Simulataneous Dual-Band AP | Number of SSID Supported | Wi-Fi as WAN and AP | Max. AP Supported By AP Controller | |
HD2 | 802.11ac/a/b/g/n | 802.11ac/a/b/g/n | 2x2 MIMO, ac: 5GHz:866Mbps b/g/n: 2.4GHz:300Mbps, 5GHz:300Mbps | 16 | 30 | |||
HD2 Mini | n/a | 30 | ||||||
HD4 | 802.11ac/a/b/g/n | 802.11ac/a/b/g/n | 2x2 MIMO, ac: 5GHz:866Mbps b/g/n: 2.4GHz:300Mbps, 5GHz:300Mbps | 16 | 30 | |||
HD2/4 with MFA | 802.11ac/a/b/g/n | 802.11ac/a/b/g/n | 2x2 MIMO, ac: 5GHz:866Mbps b/g/n: 2.4GHz:300Mbps, 5GHz:300Mbps | 16 | 30 | |||
On-The-Go | 802.11a/b/g/n * | 802.11a/b/g/n * | 2.4GHz:150Mbps/ 5GHz:150Mbps | 16 | ||||
700 | 802.11ac/a/b/g/n | 802.11a/b/g/n | 2x2 MIMO, ac: 5GHz:866Mbps b/g/n: 2.4GHz:300Mbps, 5GHz:300Mbps | 16 | 30 | |||
BR1 IP55 | 802.11ac/a/n | 802.11b/g/n | 2x2 MIMO, 2.4GHz:300Mbps/ 5GHz:866Mps | 16 | ||||
BR2 IP55 | 802.11ac/a/n | 802.11b/g/n | 2x2 MIMO, 2.4GHz:300Mbps/ 5GHz:866Mps | 16 | ||||
BR1 IP67 | 802.11b/g/n | 2.4GHz: 150Mbps | 16 | |||||
HD2 IP67 | 16 | 10 |
PepVPN | SF Hot Failover | SF WAN Smoothing | SF Bandwidth Bonding | PepVPN/SF Peers | SF / PepVPN Throughput (unencrypted) | SF / PepVPN Throughput (256-bit AES) | |
BR1 Classic | 2/5 * | 40 Mbps | 20 Mbps | ||||
BR1 MK2 | 2/5 * | 40 Mbps | 20 Mbps | ||||
BR1 Mini | * | 2/5 * | 40 Mbps | 20 Mbps | |||
BR1 M2M | 2/5 * | 40 Mbps | 20 Mbps | ||||
BR1-Slim | 2/5 * | 40 Mbps | 20 Mbps | ||||
BR1-ENT | 2/5/20 * | 100 Mbps | 60 Mbps | ||||
BR1-Pro | 2/5 * | 40 Mbps | 20 Mbps | ||||
Hotspot | 2 | 40 Mbps | 20 Mbps | ||||
Transit | * | * | 2 | 100 Mbps | 60 Mbps | ||
PepVPN | SF Hot Failover | SF WAN Smoothing | SF Bandwidth Bonding | PepVPN/SF Peers | SF / PepVPN Throughput (unencrypted) | SF / PepVPN Throughput (256-bit AES) | |
HD2 | 2/20 * | 120 Mbps | 55 Mbps | ||||
HD2 Mini | 2/20 * | 100 Mbps | 60 Mbps | ||||
HD4 | 2/20 * | 150 Mbps | 120 Mbps | ||||
HD2/4 with MFA | 2/20 * | 150 Mbps | 120 Mbps | ||||
On-The-Go | * | 2 | 40 Mbps | 20 Mbps | |||
700 | 2/20 * | 100 Mbps | 60 Mbps | ||||
BR1 IP55 | * | 2 | 40 Mbps | 20 Mbps | |||
BR2 IP55 | * | 2 | 40 Mbps | 20 Mbps | |||
BR1 IP67 | 2 | 40 Mbps | 20 Mbps | ||||
HD2 IP67 | 2 | 100 Mbps | 60 Mbps |
Bonjour Forwarding | InControl Cloud Management | GPS Fleet Management | IP Passthrough Failover | High Availability | Drop-in Mode | Time-Based Configuration | URL Logging | Content Blocking | Web Filtering Blacklist | |
BR1 Classic | * | Lite | ||||||||
BR1 MK2 | * | Lite | ||||||||
BR1 Mini | * | Lite | ||||||||
BR1 M2M | * | Lite | ||||||||
BR1-Slim | * | Lite | ||||||||
BR1-ENT | * | Lite | ||||||||
BR1-Pro | * | Lite | ||||||||
Hotspot | Lite | |||||||||
Transit | Lite | |||||||||
Bonjour Forwarding | InControl Cloud Management | GPS Fleet Management | IP Passthrough Failover | High Availability | Drop-in Mode | Time-Based Configuration | URL Logging | Content Blocking | Web Filtering Blacklist | |
HD2 | Lite | |||||||||
HD2 Mini | Lite | |||||||||
HD4 | Lite | |||||||||
HD2/4 with MFA | Lite | |||||||||
On-The-Go | Lite | |||||||||
700 | Lite | |||||||||
BR1 IP55 | Lite | |||||||||
BR2 IP55 | Lite | |||||||||
BR1 IP67 | Lite | |||||||||
HD2 IP67 | Lite |
Enclosure | Dimensions | Weight | Power Input | Terminal Block | Power Output | Power Consumption | Operating Temperature | Humidity | |
BR1 Classic | Compact, Indoor Metal | 40 x 147 x 128mm | 435 grams | DC 10V–30V,2A | DC 10V - 30V, 2A | 16W (max.) | -40° – 65°C | 15% – 95% (non-condensing) | |
BR1 MK2 | Compact, Indoor Metal | 40 x 147 x 128mm | 435 grams | DC 10V–30V,2A | DC 10V - 30V, 2A | 16W (max.) | -40° – 55°C | 15% – 95% (non-condensing) | |
BR1 Mini | Compact, Indoor Metal | 105 x 110 x 30 mm | 244 grams | DC 12V – 28V 2A | DC 12V – 28V 2A | 12W (max.) | -40° – 65°C | 15% – 95% (non-condensing) | |
BR1 M2M | IP50 Compact, Indoor Metal | 26 x 97 x 120mm | 350 grams | Molex Micro-Fit DC 10V – 30V | DC 10V – 30V, 2A | 1oW (max.) | -40° – 65°C | 15% – 95% (non-condensing) | |
BR1-Slim | IP50 Compact, Indoor Metal | 26 x 97 x 120mm | 350 grams | Micro USB: 5V 2A | DC 10V - 30V, 2A | 10W (max.) | -40° – 65°C | 15% – 95% (non-condensing) | |
BR1-ENT | Compact, Indoor Metal | 40 x 147 x 128mm | 435 grams | DC 10V – 56V, 2A | DC 10V – 56V, 2A | Up to Two 802.3af PoE Outputs * | 16W (max.) | -40° – 65°C | 15% – 95% (non-condensing) |
BR1-Pro | Indoor Metal | 40 x 260 x 143 mm | 1,2 kg | DC 10V - 30V, 3A | DC 10V - 30V, 3A | 25W (max.) | -40° – 65°C | 15% – 95% (non-condensing) | |
Hotspot | Plenum-rated, Indoor Plastic | 173 (diameter) x 38 mm | 405 grams | PoE: 802.3at | 18W (max.) | -5° – 45°C | 15% – 95% (non-condensing) | ||
Transit | Compact, Indoor Metal | 185 x 97 x 33.5 mm | 590 grams | DC 12V – 48V, 2A | DC 12V – 48V, 2A | 18W (max.) | -40° – 65°C | 15% – 95% (non-condensing) | |
Enclosure | Dimensions | Weight | Power Inout | Terminal Block | Power Output | Power Consumption | Operating Temperature | Humidity | |
HD2 | Indoor Metal | 40 x 260 x 143 mm | 1,2 kg | DC 10V – 56V, 2A | DC 10V – 56V, 2A | Up to Four 802.3af PoE Outputs * | 25W (max.) | -40° – 65°C | 15% – 95% (non-condensing) |
HD2 Mini | Compact, Indoor Metal | 40 x 147 x 128 mm | 435 grams | DC 10V – 56V, 2A | DC 10V – 56V, 2A | Up to Three 802.3af PoE Outputs * | 15W (max.) | -40° – 65°C | 15% – 95% (non-condensing) |
HD4 | Indoor Metal | 50 x 177 x 292 mm | 1,9 kg | DC 12V – 56V, 4A | DC 12V – 56V, 4A | Up to Eight 802.3af PoE Outputs * | 38W (max.) | -40° – 65°C | 15% – 95% (non-condensing) |
HD2/4 with MFA | Indoor Metal | 50 x 177 x 292 mm | 1,9 kg | DC 12V – 56V, 4A | DC 12V – 56V, 4A | Up to Eight 802.3af PoE Outputs * | 38W (max.) | -40° – 65°C | 15% – 95% (non-condensing) |
On-The-Go | Low-Profile, All-Purpose | 30 x 110 x 110 mm | 195 grams | DC 10V – 24V, 2A | 20W (max.) | -10° – 65°C | 15% – 95% (non-condensing) | ||
700 | Indoor Metal | 39.5 x 260 x 143 mm | 1,2 kg | 12V–48V DC,3A | 12V–48V DC,3A | Up to Four 802.3af PoE Outputs * | 25W (max.) | -40° – 65°C | 15% – 95% (non-condensing) |
BR1 IP55 | Outdoor IP55 All-Weather | 300 x 124 x 30 mm | 435 grams | Pepwave Passive PoE Input: 12V–56V DC,2A spec_none | 1x 802.3at PoE+ Output * | 18W (max.) | -40° – 65°C | 15% – 95% (non-condensing) | |
BR2 IP55 | Outdoor IP55 All-Weather | 300 x 124 x 30 mm | 435 grams | Pepwave Passive PoE Input: 12V–56V DC,2A spec_none | 1x 802.3at PoE+ Output * | 18W (max.) | -40° – 65°C | 15% – 95% (non-condensing) | |
BR1 IP67 | Outdoor IP67 All-Weather | 141 x 162 x 101 mm | 680 grams | 802.3af PoE or 48V Passive PoE | 12W (max.) | -40° – 65°C | 15% – 95% (non-condensing) | ||
HD2 IP67 | Outdoor IP67 Metal | 230 x 310 x 66 mm | 2,65 kg | Power over Ethernet 802.3at Device: 10V–30V DC,3A * | 25W (max.) | -40° – 65°C | 15% – 95% (non-condensing) |
FCC, CE, RoHS | RF Port Lighting Immunity: ITU-T K.20 (+/- 1.5 kV) | EMark | Shock and Vibration Resistance: EN 61373:1999 IEC 61373:1999 | EN 50155: Railway Applications | EN 61000 Electromagnetic Compatibility | Hazardous Locations - Class 1 Division 2 | Verizon Certified | Sprint Certified | |
BR1 Classic | |||||||||
BR1 MK2 | |||||||||
BR1 Mini | |||||||||
BR1 M2M | |||||||||
BR1-Slim | |||||||||
BR1-ENT | |||||||||
BR1-Pro | |||||||||
Hotspot | |||||||||
Transit | |||||||||
FCC, CE, RoHS | RF Port Lighting Immunity: ITU-T K.20 (+/- 1.5 kV) | EMark | Shock and Vibration Resistance: EN 61373:1999 IEC 61373:1999 | EN 50155: Railway Applications | EN 61000 Electromagnetic Compatibility | Hazardous Locations - Class 1 Division 2 | Verizon Certified | Sprint Certified | |
HD2 | |||||||||
HD2 Mini | |||||||||
HD4 | |||||||||
HD2/4 with MFA | Soon | ||||||||
On-The-Go | n/a | n/a | |||||||
700 | n/a | n/a | |||||||
BR1 IP55 | n/a | n/a | |||||||
BR2 IP55 | n/a | n/a | |||||||
BR1 IP67 | |||||||||
HD2 IP67 |
