Yahboom STM32 2wd Self-Balancing Robot,Two-Wheeled Intelligent Robot Chassis Kit,PID Obstacle Avoidance Encoder Motor (Standard Kit)
Product details
| Management number | 222906602 | Release Date | 2026/05/09 | List Price | US$28.16 | Model Number | 222906602 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【5 kits to choose】Five kits to choose from: standard version, four-way patrol module, 2.4G handle, K210 vision module, TminiPlus radar. Use STM32F103RCT6 as the main control, with rich GPIO interface, providing 51 programmable input/output pins, to meet the application development of large-scale projects such as robot control system and balance car system. If you want to buy accessories, please contact Yahboom to get the link to avoid missing accessories.
- 【Excellent hardware】Equipped with STM32 balance car driver board, providing: two-way encoder motor, wireless handle, OLED display, radar, Bluetooth, ultrasonic, K210 vision module, four-way patrol and other peripheral interfaces. Four-way patrol can realize right-angle turns and high-difficulty patrol; radar realizes all-round 360-degree perception; K210 vision module realizes recognition, patrol and interaction functions, helping you quickly build your own STM32 balance car project.
- 【APP control function gameplay】Provide Bluetooth control APP, only applicable to Android. The main control interface, PID debugging interface, and waveform display can adjust parameters at any time and observe the movement status of the balance car at any time. 5 basic gameplays, posture recognition, and six-axis IMU are used to achieve automatic balance; it adopts a three-layer structure, with an effective load of 4KG, and it can still be remotely controlled while carrying weight.
- 【Burn the program】The program contains up to 20 functional ways of playing, and there is no need to download the program additionally, so you can play it as soon as you get it. Just turn the wheel gently to switch different functional modes, which greatly improves the user experience.
- 【STEM kit for everyone】The STM32 balance car is easy to assemble, suitable for get some hands-on experience and learn basic programming knowledge. Professional robot enthusiasts can also enjoy it by customizing and adding more functions to this kit. We provide detailed English code and source code. If you have any questions during use, please contact us for technical help.
| ASIN | B0DJSHT8SG |
|---|---|
| Size | 3 inches (W) x 7.5 inches (L) x 5.5 inches (H) |
| Color | Black |
| Scale | full-size |
| Theme | Science Fiction |
| Edition | Standard Kit |
| character | STM32 Balancing Robot |
| Brand Name | Yahboom |
| Model Name | STM32 Balancing Robot |
| Unit Count | 1.0 Count |
| Manufacturer | Yahboom |
| Model Number | STM32 Balancing Robot - Standard Kit |
| Power Source | battery |
| Material Type | Aluminum |
| Operation Mode | manual |
| Outer Material | Metal |
| Collection Name | Robotics |
| Item Dimensions | 7.5 x 3 x 5.5 inches |
| Toy Figure Type | Interactive Gaming Figure |
| Number of Players | 1 |
| Additional Features | Remote Control |
| Included Components | STM32 expand board, balance car chassis, motor, wheel |
| Number of Batteries | 1 9V batteries required. (included) |
| Is Assembly Required | Yes |
| Age Range Description | 16+ |
| Educational Objective | Learning and practicing STEM skills |
| Are Batteries Required | Yes |
| Play Activity Location | Floor |
| Manufacturer Part Number | STM32 Balancing Robot |
| Item Dimensions L x W x H | 7.5"L x 3"W x 5.5"H |
| Manufacturer Maximum Age MONTHS | 480.0 |
| Manufacturer Minimum Age MONTHS | 192.0 |
| Manufacturer Warranty Description | 90 Day Warranty Against Manufacturer Defects |
