Blue Sea Systems 4320 Water-Resistant Circuit Breaker Switch Panel, Gray, 4 Positions
Product details
| Management number | 219304575 | Release Date | 2026/05/03 | List Price | US$17.88 | Model Number | 219304575 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Blue Sea Systems Water-Resistant Circuit Breaker Panel, 4 Position, Gray. Nominal Voltage: 12V DC, Max Operating Amperage: 45A, Terminal Type: 1/4" Male Quick Connect, Hardware: Stainless Steel #6 x 5/8" mounting screws, Ring Terminal Size: M5 (#10)..Illuminated 15A circuit breakers provide switching, ON indication and overcurrent protection.Industry-standard sizes and mounting allow these panels to be easily retrofitted in an existing application.Polycarbonate/ABS panel surface is UV-stabilized, flame retardant, and will not corrode.Silicon breaker boots and gasket protects against water ingress. Panel front is IP66 when mounted with gasket in place - protected against powerful water jets (see inside back cover)..
- Blue Sea Systems Water-Resistant Circuit Breaker Panel, 4 Position, Gray. Nominal Voltage: 12V DC, Max Operating Amperage: 45A, Terminal Type: 1/4" Male Quick Connect, Hardware: Stainless Steel #6 x 5/8" mounting screws, Ring Terminal Size: M5 (#10).
- Illuminated 15A circuit breakers provide switching, ON indication and overcurrent protection
- Industry-standard sizes and mounting allow these panels to be easily retrofitted in an existing application
- Polycarbonate/ABS panel surface is UV-stabilized, flame retardant, and will not corrode
- Silicon breaker boots and gasket protects against water ingress. Panel front is IP66 when mounted with gasket in place - protected against powerful water jets (see inside back cover).
| UPC | 632085043209 |
|---|---|
| Color | Gray |
| Model | 4320 |
| Wattage | 180 watts |
| Terminal | Quick Connect,screws |
| Brand Name | Blue Sea Systems |
| Unit Count | 1.0 Count |
| Item Weight | 8 ounces |
| Part Number | 4320 |
| Switch Type | Circuit Breaker |
| Circuit Type | 4-way |
| Contact Type | Make-before-break |
| Control Type | manual |
| Manufacturer | Blue Sea Systems |
| Actuator Type | Push Button |
| Material Type | Plastic |
| Mounting Type | Panel Mount |
| Connector Type | Quick Connect,screws |
| Control Method | Touch |
| Current Rating | 15 Amps |
| Item Type Name | Water-resistant Panel |
| Operation Mode | manual |
| Controller Type | Ring |
| Item Dimensions | 6.8 x 5.5 x 4 inches |
| Number of Items | 1 |
| Contact Material | Stainless Steel |
| Operating Voltage | 12 Volts |
| Specification Met | Ip66 |
| Compatible Devices | 12V DC devices with 1/4" Male Quick Connect terminal, up to 45A |
| Included Components | Panel, 15 common square labels, stainless steel #6 5/8" mounting screws, Instructions |
| Number of Positions | 4 |
| Warranty Description | Lifetime |
| Connectivity Protocol | X-10 |
| Compatible with Vehicle Type | Marine |
| International Protection Rating | IP66 |
